Somta Series 203 – 28mm HSS Morse Taper Shank Drill MT3 DIN 345

HSS Morse Taper Shank Drill 28.00mm – Somta Series 203 The SOMTA 2032800 – 28.00 mm HSS Morse Taper Shank Drill is a high-performance drilling tool engineered for heavy-duty applications in...
$217.75
$0.00
$217.75
(-0%)
Vendor: SOMTA
SKU: 2032800
Availability: In Stock
Subtotal: $217.75
SOMTA DRILLS Somta Series 203 - HSS Morse Taper No.3 Thinned Point Drill 28mm

Somta Series 203 – 28mm HSS Morse Taper Shank Drill MT3 DIN 345

$0.00 $217.75

Somta Series 203 – 28mm HSS Morse Taper Shank Drill MT3 DIN 345

$0.00 $217.75

HSS Morse Taper Shank Drill 28.00mm – Somta Series 203

The SOMTA 2032800 – 28.00 mm HSS Morse Taper Shank Drill is a high-performance drilling tool engineered for heavy-duty applications in industrial and workshop environments. Designed to fit directly into Morse taper machine spindles, it ensures rigid, accurate alignment and high torque transmission. Made from premium High-Speed Steel (HSS) and finished with a bright or steam-tempered surface, this drill offers excellent durability, wear resistance, and thermal stability. The 118° point angle delivers smooth penetration, while the precision-ground flutes enable efficient chip evacuation.

Key Features & Benefits

  • Morse Taper Shank – Allows direct mounting in lathe or mill spindles for maximum torque and alignment accuracy.
  • 118° Standard Point – Provides controlled starts and reliable drilling in a wide range of materials.
  • High-Speed Steel (HSS) – Maintains sharpness and toughness under demanding cutting conditions.
  • Precision-Ground Flutes – Optimize chip flow and minimize tool wear during continuous use.
  • Heavy-Duty Design – Ideal for large-diameter drilling tasks in structural steel, cast iron, and non-ferrous metals.
  • Steam-Treated or Bright Finish – Enhances surface hardness and reduces friction (verify finish per batch).

Technical Specifications

  • Part No: 2032800
  • Cutting Diameter: 28.00 mm
  • Shank Type: Morse Taper (MT, size to be confirmed based on machine fitment)
  • Material: High-Speed Steel (HSS)
  • Point Angle: 118°, Standard
  • Helix Angle: Standard Right-Hand Spiral
  • Flute Type: Precision-Ground
  • Finish: Bright or Steam Tempered
  • Standard: DIN 345 or ANSI Equivalent

Why Choose the SOMTA 2032800 Morse Taper Drill?

  • Designed for Large-Diameter Drilling – Trusted for structural and industrial-grade fabrication work.
  • Rigid Setup & Minimal Runout – Morse taper ensures consistent results and safe operation at high torque.
  • Long-Lasting HSS Construction – Withstands heat, pressure, and repeated use without rapid dulling.
  • Compatible with MT Spindle Machines – Ideal for use in lathes, vertical drills, and horizontal boring machines.

The SOMTA 2032800 28.00 mm Morse Taper Shank Drill offers the strength, reliability, and precision needed for large-diameter, deep-hole metal drilling, making it an essential tool for professional machining and fabrication environments.
